ATOS ScanBox Series 4
Mobile stand-alone measuring solution for the production environment
With the ATOS ScanBox 4105 optical 3D measuring machine, you can quickly and efficiently inspect small and complex parts up to 500 mm in size. The compact and mobile system is ready for immediate use thanks to the plug&play concept and can be easily repositioned if required. Start all measuring procedures and inspection processes via the kiosk interface and the Virtual Measuring Room (VMR) in ZEISS INSPECT.
Ready for immediate use and easy handling
Use the ATOS ScanBox 4105 for efficient quality assurance of your injection and die-cast parts, tools or formed, stamped and bent parts. See the performance of the compact 3D measuring machine for yourself
Plug & Play
Turnkey 3D measuring machine
As ATOS ScanBox 4105 works with 100-240 V, there is no need for complex configurations: Simply connect, switch on and start the measuring program.
Easy operation
Automated process control at the touch of a button
Program and control the ATOS ScanBox 4105 via a simple user interface - the Kiosk Interface. Your plant employees do not need any special technical knowledge to operate it: Insert the part, select the measuring program and press the start button.
Fast & precise
ATOS Q meets high metrological demands
The integrated ATOS Q sensor provides quality information in a high level of detail for subsequent analysis in a short time. By using a multi-part fixture, you can measure several parts in one run - even in 24/7 operation if required: This allows you to increase your throughput, produce fewer rejects and standardize your quality assurance.
Virtual Measuring Room
Real environment in a virtual simulation
The virtual measuring room (VMR) is the central control and measurement planning software for all elements of the optical 3D measuring machine. In it, the real environment is functionally represented in a virtual simulation. The VMR consists of a robot with one sensor, the programming, including the kinematics of the robot paths, the part, and the measurement plan. Thanks to the VMR, the user does not need any special robot expertise. All robot movements are simulated in the virtual measuring room before execution and checked for safety.
Effective analysis tool
ZEISS INSPECT offers everything from a single source
Scanning, inspection and reporting: Evaluate nominal-actual comparisons as well as GD&T. Implement necessary corrections directly thanks to easy-to-understand results. With ZEISS INSPECT you can carry out complete analyses, receive comprehensive reporting and integrate measurement results into existing processes.
